PSA Nitrogen generator

     Operating conditions

• Ambient temperature range 5°C to 50°C

• Nitrogen outlet pressure 5 to 9 barG

• Nitrogen dew point -50°C ( -70°C)

• Air inlet pressure 7.5 to 10barG

• Inlet air quality ISO: 8573.1:2010 class 1.4.1.

• Pressure dew point 3°C

• Filtration grade 0.01 micron

• Power supply 110-240V / 50-60Hz

     Key Features

• Standard Features

• Stainless steel piping

• Colour touch screen control

• Built in purity analyser for constant monitoring

• Data-logging via USB interface

• Modbus TCP communication

• Remote start/stop relay

• Designed for dynamic pressure loading

    Optional add-ons

• Flow control valve – flow & purity adjustmen

• Energy saving valve – reduces compressed air usage

• during turn down

• Purity control – off spec purge

• Sequential start/stop – one button operation

• SMS alarm

• Remote monitoring

• Audio-visual alarm

• and others

    Typical applications

• Petrolchemical Industries.

• Electronics

• Food packaging

• Inerting

• Plastics

• Tyre filling

• Laser Cutting

• Coal, Oil & Gas Mining.

• Fire Fighting/Preservation.

• Airport Ground Support.

• Antique Protection

• Environment Protection.

• For Lab Researching.
